C-3POEM915P5 – V3 902 – 928MHz
OEM Monopole Omnidirectional Antenna 5.1dBi 915Mhz PCB-LESS- V3.
Description: Robust and reliable construction for use in electronic circuits; Stamped in Brass Metal Muntz with ¾ hardness; Coated with layers of copper, nickel-chromium and gold; Unique gold coating formula, created by C-3PO, allows radio frequency to propagate only in gold, a pure metal, which acts as a spurious filter and increases reception sensitivity and transmission propagation; Supports vibration up to 60Hz <<< NEW!!
ELECTRICAL | |
FREQUENCY RANGE: | 902 - 928Mhz |
IMPEDANCE: | 50Ω |
BANDWIDTH: | ±4% |
SWR: | <1.2:1 |
MAX SUPPORTED POWER: | 15W |
POLARIZATION: | Vertical or Horizontal |
GAIN: | 5.1dBi |
MECHANICS | |
STANDARD CONNECTION: | Direct PCB mounting |
UHF ELEMENTS: | H:28mm x L: 32.822mm x W: 0.30mm |
TECHNICAL COATING: | Special electroplating formula for Copper, Nickel-Chromium and Gold |
TYPICAL WEIGHT: | approx. 0.7g |
SEVERAL | |
TYPE OF USE: | Embedded in electronic circuits |
BASE MATERIAL: | Brass Metal Muntz Stamped |
